Specification
| Basi | Caetegory | 22K | |
| Model | S3-Q24K23BD.ALWBABN | ||
| Model Performance | |||
| Capacity | Cooling | W | 6300 |
| BTU/Hr | 21496 | ||
| min~max | BTU/Hr | 5118~23885 | |
| EER/COP | 10.41 | ||
| ISEER | _ | ||
| Air Circulation | Indoor/Outdoor | CFM | 653/1520 |
| Noise Level | Indoor (Hi/ Mid / Lo /SL) | dB-A(+1) | 46/40/36/34 |
| Outdoor | dB-A(+1) | 56 | |
| ELECTRICAL | |||
| Compressor | Type/Gas | Dual Rotary / R-32 | |
| Power Supply | Phase/Volatge/Frequency | Ø/V/Hz | 1/220~240/50 |
| Power Input | Cooling | W | 2065 |
| Running Current | Cooling | A | 9.5 |
| Tool | |||
| Indoor | Tool | SK | |
| Outdoor | Tool | U24A | |
| Condenser Type | Material | ø7mm CU (Black fin and tube) | |
| Interconnecting pipe | Liquid Side | mm(in) | 6.35(1/4) |
| Gas Side | mm(in) | 12.7(1/2) | |
| DIMENSION & WEIGHT | |||
| Dimension | Indoor (W*H*D) | mm | 998 * 345 * 210 |
| Outdoor (W*H*D) | mm | 870 * 650 * 330 | |
| Net Weight | Indoor | Kg | 11.5 |
| Outdoor | Kg | 40 | |
| Stuffing | Indoor + Outdoor (CBU) | 40 Ft (HC) | 130 |
| FEATURES | |||
| H’Cool | √ | ||
| Monsoon Comfort | √ | ||
| Wi-Fi | × | ||
| Active Energy Control |
